A true trail machine we couldn’t wait to have on our bikes and get to you. Featuring an updated debonair™ air spring paired with our charger™ 2.1 damper for unmatched trail control for every sweeping corner or loamy drop in. Ultra-low friction SKF wiper seals and maxima plush damping fluid all work overtime to reduce friction, silence noise, and provide lasting fork performance.
Features
- updated highly tunable debonair™ air spring offers a buttery smooth feel off the top and maintains a higher ride height for increased confidence in steep terrain
- designed to reduce hand fatigue and fight unwanted friction, the charger™ 2.1 damper increases confidence and control over every trail
- charger™ 2.1 rc2 damper option featuring independent high and low-speed compression adjust
- charger™ 2.1 rct3 damper option featuring 3-position compression adjust (open/pedal/firm) with low-speed compression adjust
- ultra-low friction SKF wiper seals provide long-lasting fork performance and improve overall suspension feel
- maxima plush damping fluid reduces friction and silences damper noise
- gloss silver signature colourway and ultimate high gloss black
- ultimate foil graphics package
specifications
model designator (SF): ultimate
wheel size: 29″
travel (mm): 130mm, 140mm, 150mm
damper type: charger 2.1 rc2
fork offset: 51mm (29″)
maxle included: maxle stealth
colour (fs): gloss black
steerer: 1.5″ tapered
axle: 15x110mm boost™
axle to crown (mm): 541, 551, 561
brake type (FD): disc
crown material: forged, hollow aluminium
lower leg material: magnesium
upper tube finish: fast black
upper tube type: 35mm tapered wall aluminium
damper adjust: crown
damping adjustments: extl begin stroke rebound, low-speed comp, high-speed comp
volume reducer: 1/4 tokens
spring: debonair
max tire diameter (mm): 770
max tire width (mm): 81
maximum rotor size: 220mm
minimum rotor size: 180mm
crown od (mm): 58
part weight (g): 1790
